More*Model No.: | F601801 |
---|---|
*Place Of Origin: | Fujian, China |
*Material: | Natural Clay |
*Size: | 600*1200*18mm |
*Color: | White |
*Packaging Details: | 31kgs/sqm |
*Payment Terms: | L/C, T/T, Western Union |
*Port: | Xiamen |
*Delivery Time: | 20 days after receiving deposit |
*Certification: | CE, ISO9001:2008 |
As a new product, terracotta panel not only has diverse features and natural colors, but also is an environment-friendly property including soundproofing, heat preservation and frost resistance. As the world pays more attention to environment protection, more terracotta products are being adopted by architect and designers. For more high-end public buildings in the world, terracotta panel can also help the projects become more famous and tasteful to some extent.
Removable Architectural Composite Terracotta Facade Specification:
Model No.: |
F601801 |
Brand Name: |
LOPO |
Material: |
Natural Clay |
Supply Ability: |
2500sqm/day |
Size(W*L*T): |
600*1200*18mm |
MOQ: |
1x20’GP |
Color: |
White |
Packaging: |
Wooden Crate |
Weight: |
31kgs/sqm |
Loading: |
619.20sqm/20’GP |
Certification: |
CE, ISO9001:2008 |
Lead Time: |
20 days after receiving deposit |
Customized Design: |
Available |
Payment Term: |
L/C, T/T, Western Union |
Terracotta Facade Panel Regular:
Regular Product | Color: White/Yellow/Grey/red/Brown Surface Treatment: Flat/Grooved/Sanded/Glazed/Strip-line/Wood Grain/Corrugated |
Dry Hanging Terracotta Panel | Length: 250-1500mm Width: 150-600mm Thickness: 18mm or 30mm |
Small Size Terracotta Panel | Width: 100-200mm Thickness: 10-15mm |
Light Weight Terracotta Panel | Length: 250-1500mm Width: 150-600mm Thickness: 10-15mm |
Note: | Customized is welcome! Just send us your design or sample. |
Architectural Terracotta Facade Technical Data Sheet:
Terracotta Panel Technical Data Sheet |
||||
NO. |
Contents |
(300*600*18mm) Terracotta Panel |
China N. S. GB/T4100-2006 |
EN14411 standard |
1 |
Water Absorption |
5.4% |
(II) 6-10% |
(II) 6-10% |
2 |
Net Weight |
31kg/m2 |
No value |
No value |
3 |
Breaking Strength |
3475N |
≥ 900N |
≥ 750N |
4 |
Frost Resistance |
No crack under -60 centigrade |
Tested value of the report |
Tested value of the report |
5 |
Modulus of Rupture |
Avg. 13.1Mpa, min 11.8Mpa |
Avg. ≥ 9Mpa, single value≥ 8Mpa |
Avg. ≥ 9Mpa, single value≥ 8Mpa |
6 |
Earthquake Resistance |
Over 8 degree |
No value |
No |
7 |
Test Under Simulated Wind Load |
No breakage under 10Kpa |
No value |
No |
8 |
Sound Insulation |
Noise reduction by over 8dB |
7-10dB |
No |
9 |
Wind Pressure |
9kPa |
Tested value of the report |
Tested value of the report |
10 |
Heat Conductivity |
0.32 w/m.k |
No value |
No |
11 |
Fire Resistance |
level A1 |
No value |
No |
12 |
Resistance to Acid and Alkali |
Level UA |
Tested value of the report |
No |
13 |
Radioactivity |
Class-A decorative material |
No value |
No |
14 |
Right Angle |
0.1%- -0.2% |
Within ±1% |
No |
15 |
Size Error |
300L: 0.1%- -0.4% 600L: 0.2%- -0.5% |
Within±2% , max is within ±2mm, |
No |
16 |
Thickness Error |
Within ±4.5% |
Within ±10% |
No |
17 |
Diagonal Line |
-0.5 ~ +0.2 Max 1.0mm |
Within ±2% |
No |
Composite Terracotta Facade Feature and Benefits:
1. Natural terracotta clay materials, eco-friendly
2. Rich color and surface design available
3. Hollow structure and light weight design
4. No-static and no-radiation
5. Never fade, strong and durable
6. Convenient fixing installation, safe and reliable
7. Wind and earthquake resistance
8. Anti-fire, anti-freeze, heat preservation and sound insulation
9. Self-cleaning, easy maintenance
LOPO China Production Ability:
1. Domestic longest roller kiln(260-meter) with 428 firing units;
2. 80,000 square meters open stockyard with the daily reserve of natural clay raw materials amounts to 300,000 tons;
3. The new workshops and production lines under construction;
4. The semi-production indoor repository with storage capacity of 150,000 tons;
5. The automatic production line with the processing capacity of shaping, cutting and polishing;
6. A batch storage system which can reserve 12,000 tons of prepared clay material;
7. Imported molding machines of vacuum extrusion from Italy.
